Matrix COSEC READER CB citac kartica
Ostalo- Proizvod iz grupe: Čitači kartica
- Proizvođač: Ostalo
Matrix COSEC READER CB čitač kartica
Nije uključen Card Reader modul
– Povezivanje sa Panelima/Kontrolerima drugih proizvođača preko Wiegand interfejsa
– Podržava EM Prox, Mifare Smart i HiD iClass module kartica
– Otvaranje vrata preko BLE korisničkog telefona
– RS-232, RS-485 i Wiegand interfejs
– Tamper detekcija
– 4 kolor LED indikatora i Buzzer (zvučni signal)
– Kompatibilan sa svim COSEC kontrolerima za vrata (osim COSEC DOOR FOT)
Specifikacije:
| GENERAL | |
|---|---|
| Type | A slave reader which can work with COSEC Door Controllers and 3rd party Wiegand interface Access Control Panel. |
| Credential Support | Card and Mobile Credential over BLE |
| CAPACITY | |
| User Capacity | Depends on Master Device |
| Card Storage Capacity | Depends on Master Device |
| CARD READER | |
| Type of Card Support | MIFARE Classic® Smart, HID iCLASS, EM Prox, HID Prox, (CPM module Required; Supports DOOR CPM module) |
| Card Read Range | Up to 5cm from Device Surface |
| INTERFACE | |
| Tamper Detection | Yes |
| AUDIO VISUALS | |
| LED | 4 Single Color LEDs LED 1 - ALLOWED, LED 2 - DENIED, LED 3 - STATUS *, LED 4 - ALARM * * Not used in Wiegand Communication |
| Buzzer | Yes |
| COMMUNICATION | |
| Built in Bluetooth | YES (BLE 4.0 and above) Bluetooth Functionality will Work with COSEC APTA Application. |
| Reader Interface | RS-232, RS-485 and Wiegand |
| Interface Support Length | RS232 (3meter), RS485 (1200meter), Wiegand (150meter) |
| POWER | |
| Input Power | 5-16 VDC@ max 150MA |
| ENVIRONMENTAL | |
| Operating Temperatures | 0 °C to +50 °C (32°F to 122°F) |
| Humidity Range | 10% to 95% RH Non-Condensing |
| CERTIFICATION | |
| Certification | CE, RoHS, BIS and FCC Part 15 |
| PACKAGING | |
| Packaging | 1. Main unit - COSEC READER CB 2. Back Plate 3. Reader Cable Assembly 4. Screws and other Mounting Accessories |
Matrix COSEC READER CB čitač kartica
Nije uključen Card Reader modul
– Povezivanje sa Panelima/Kontrolerima drugih proizvođača preko Wiegand interfejsa
– Podržava EM Prox, Mifare Smart i HiD iClass module kartica
– Otvaranje vrata preko BLE korisničkog telefona
– RS-232, RS-485 i Wiegand interfejs
– Tamper detekcija
– 4 kolor LED indikatora i Buzzer (zvučni signal)
– Kompatibilan sa svim COSEC kontrolerima za vrata (osim COSEC DOOR FOT)
Specifikacije:
| GENERAL | |
|---|---|
| Type | A slave reader which can work with COSEC Door Controllers and 3rd party Wiegand interface Access Control Panel. |
| Credential Support | Card and Mobile Credential over BLE |
| CAPACITY | |
| User Capacity | Depends on Master Device |
| Card Storage Capacity | Depends on Master Device |
| CARD READER | |
| Type of Card Support | MIFARE Classic® Smart, HID iCLASS, EM Prox, HID Prox, (CPM module Required; Supports DOOR CPM module) |
| Card Read Range | Up to 5cm from Device Surface |
| INTERFACE | |
| Tamper Detection | Yes |
| AUDIO VISUALS | |
| LED | 4 Single Color LEDs LED 1 - ALLOWED, LED 2 - DENIED, LED 3 - STATUS *, LED 4 - ALARM * * Not used in Wiegand Communication |
| Buzzer | Yes |
| COMMUNICATION | |
| Built in Bluetooth | YES (BLE 4.0 and above) Bluetooth Functionality will Work with COSEC APTA Application. |
| Reader Interface | RS-232, RS-485 and Wiegand |
| Interface Support Length | RS232 (3meter), RS485 (1200meter), Wiegand (150meter) |
| POWER | |
| Input Power | 5-16 VDC@ max 150MA |
| ENVIRONMENTAL | |
| Operating Temperatures | 0 °C to +50 °C (32°F to 122°F) |
| Humidity Range | 10% to 95% RH Non-Condensing |
| CERTIFICATION | |
| Certification | CE, RoHS, BIS and FCC Part 15 |
| PACKAGING | |
| Packaging | 1. Main unit - COSEC READER CB 2. Back Plate 3. Reader Cable Assembly 4. Screws and other Mounting Accessories |
