| Model | Gigabyte 1600W UD1600PM PG5 AI TOP 80+ Platinum Modular PCIe 5.0 ATX PC napajanje |
| Verzija napajanja | PG5 AI TOP |
| Ukupna snaga | 1600W |
| Energetska efikasnost | 80 Plus Platinum |
| Standard | ATX V3.1 |
| AC ulaz | 100-240Vac |
| DC izlaz | Ulazna jačina struje: 15-7.5A Ulazna frekvencija: 60-50Hz |
| PFC | Aktivni |
| Hlađenje | Ventilator 140mm |
| Upravljanje kablovima | Modularni |
| PCI-Express konektori | 8 pin (6+2) |
| Ostali konektori | ATX/MB 20+4 Pin x 1 : 610mm 1 CPU/EPS 4+4 Pin x 2 : 650mm 2 PCI-E 16 Pin x 2 : 700mm 2 PCI-E 16 Pin to PCI-E 8 pin x 2 : 700mm 2 SATA x 16 : 650mm+150mm+150mm+150mm 4 4 Pin Peripheral x 6 + 4 Pin floppy x 2 : 600mm+150mm+150mm+150mm 2 |
| MTBF | 100.000 hours |
| Dodatne karakteristike | OVP - Over Voltage protection OPP - Over Power protection SCP - Short Circuit protection UVP - Under Voltage protection OCP - Over Current protection OTP - Over Temperature protection |
| Dimenzije | 190x150x86mm |
