XS-XVR6216S-4KL snimac
OstaloŠifra: 179648
- Proizvod iz grupe: IP mrežni snimač
- Proizvođač: Ostalo
Dostupno:
Maloprodajna cena:
94.462,00 rsd.
cena za odloženo plaćanje i kupovinu na rate
WebCena:
78.718,00 rsd.
cena za web porudžbine i avansno plaćanje
Popust:
15.744,00 rsd.
Model: XS-XVR6216S-4KL snimač
DVR 5u1 X-Security 16 CH
HDTVI / HDCVI / AHD / CVBS / 16+8 IP; 4KL (7FPS) / 5M (12FPS) / 4M/3M (15FPS) 1080P/720P (25FPS) | 1 CH audio; Izlazi 4K HDMI & VGA; Prostor za 2 hard diska;
Specifikacije:
| Brand | X-Security |
| Video format | HDTVI / HDCVI / AHD / CVBS / IP |
| Video inputs | 16 BNC Channels: HDTVI: Up to 5Mpx HDCVI: Up to 4K AHD: Up to 5Mpx CVBS |
| Hybrid configuration | Up to 24 IP Channels (8Mpx), replacing all the BNC channels |
| Video outputs | 1 HDMI Full HD, 1 VGA |
| Audio inputs | 1 Channel RCA |
| Audio outputs | 1 Channel RCA |
| Bidirectional audio | Reusing the audio input/output |
| Supports audio | Over coax |
| Video / audio compression | H.264+/H.264 / G.711u |
| Display resolution | 3840x2160, 2560x1440, 1920x1080, 1280x1024, 1280x720, 1024x768 |
| Total bandwidth | 96 Mbps |
| Recording resolution | 4K / 6Mp / 5Mp / 4Mp / 3Mp / 1080p / 1080N / 720p |
| Main Stream coding | HDCVI: 4K (7FPS) / 5MP (12FPS) / 4MP / 3MP (15FPS) / 1080p / 720p (25 FPS) HDTVI / AHD: 5MP (12FPS) / 4MP / 3MP (15FPS) / 1080p / 720p (25 FPS) CVBS: 960H / D1 / HD1 / BCIF / CIF / QCIF (25 FPS) |
| Extra Stream coding | D1 / CIF / QCIF (1~25 FPS) |
| Simultaneous multifunction | Pentaplex: Live, Recording, Playback, Backup and Remote Access |
| Alarms | No |
| Video analysis | VCA: Tripwire | Area intrusion | Abandoned object | Face detection |
| Recording method | Manual, programmed, motion detection, alarm |
| Backup | USB (Memory, HDD, CD-RW, DVR-RW) / Network |
| Internal memory | 2 HDD SATA 3.5\ of up to 6TB (not included) |
| Communication | RS485 (PTZ) / 2 x USB (Mouse and backup) / RJ45 10/100 (Ethernet) |
| Remote access | Web browser (ActiveX), mobile phone application or PSS software |
| Power | DC 12 V / 5 A |
| Dimensions / Weight | 53 (H) x 375 (W) x 287 (D) mm / 2.35 Kg |
Model: XS-XVR6216S-4KL snimač
DVR 5u1 X-Security 16 CH
HDTVI / HDCVI / AHD / CVBS / 16+8 IP; 4KL (7FPS) / 5M (12FPS) / 4M/3M (15FPS) 1080P/720P (25FPS) | 1 CH audio; Izlazi 4K HDMI & VGA; Prostor za 2 hard diska;
Specifikacije:
| Brand | X-Security |
| Video format | HDTVI / HDCVI / AHD / CVBS / IP |
| Video inputs | 16 BNC Channels: HDTVI: Up to 5Mpx HDCVI: Up to 4K AHD: Up to 5Mpx CVBS |
| Hybrid configuration | Up to 24 IP Channels (8Mpx), replacing all the BNC channels |
| Video outputs | 1 HDMI Full HD, 1 VGA |
| Audio inputs | 1 Channel RCA |
| Audio outputs | 1 Channel RCA |
| Bidirectional audio | Reusing the audio input/output |
| Supports audio | Over coax |
| Video / audio compression | H.264+/H.264 / G.711u |
| Display resolution | 3840x2160, 2560x1440, 1920x1080, 1280x1024, 1280x720, 1024x768 |
| Total bandwidth | 96 Mbps |
| Recording resolution | 4K / 6Mp / 5Mp / 4Mp / 3Mp / 1080p / 1080N / 720p |
| Main Stream coding | HDCVI: 4K (7FPS) / 5MP (12FPS) / 4MP / 3MP (15FPS) / 1080p / 720p (25 FPS) HDTVI / AHD: 5MP (12FPS) / 4MP / 3MP (15FPS) / 1080p / 720p (25 FPS) CVBS: 960H / D1 / HD1 / BCIF / CIF / QCIF (25 FPS) |
| Extra Stream coding | D1 / CIF / QCIF (1~25 FPS) |
| Simultaneous multifunction | Pentaplex: Live, Recording, Playback, Backup and Remote Access |
| Alarms | No |
| Video analysis | VCA: Tripwire | Area intrusion | Abandoned object | Face detection |
| Recording method | Manual, programmed, motion detection, alarm |
| Backup | USB (Memory, HDD, CD-RW, DVR-RW) / Network |
| Internal memory | 2 HDD SATA 3.5\ of up to 6TB (not included) |
| Communication | RS485 (PTZ) / 2 x USB (Mouse and backup) / RJ45 10/100 (Ethernet) |
| Remote access | Web browser (ActiveX), mobile phone application or PSS software |
| Power | DC 12 V / 5 A |
| Dimensions / Weight | 53 (H) x 375 (W) x 287 (D) mm / 2.35 Kg |
